NabCat 2612 HYB
NabCat 2612 Hybrid is a real power plug of a steel service catamaran designed for tough use. There is a high level of comfort on board with a large booth and bright cozy cabins. You will experience practical solutions and consistently good technical quality.
This vessel is delivered as a plug-in-hybrid as standard, but can be delivered with conventional propulsion machinery on request.
| Construction | Catamaran |
| Design | Marin Design |
| Material | Aluminium (steel on request) |
Main dimensions
| Length o.a. | 26,00 m |
| Breadth o.a. | 12,00 m |
| Breadth hull | 4,00 m |
| Depth | 4,80 m |
Capacities
| Fuel | 37,8 m³ |
| Water | 18,8 m³ |
| Sea ballast | 102,9 m³ |
| Load capacity deck | Approx. 80 t |
| Gross deck area behind wheelhouse | Approx. 173 m2 |
| Speed, no payload | Approx. 11 knots |
| Trade area | 5 |
| BP | Approx. 26 ton |
Cabins
| 6 x one-man cabins | |
Propulsion machinery*
| Engine | 2 x Danfoss Editron PM 575 kW |
| Energy Storage System | 1128 kWh |
| Gearbox | 2 x Kumera KMG 450 |
| Propeller | Helseth 4T450/170 pitch propeller |
| Bow thrusters | 2 x PMH 132 kW |
| *Can be delivered with diesel mechanical propulsion machinery on request |
Generator
| Catepillar C18, 5003kW, 400V60Hz |
| Catepillar C933 , 310ekW, 400V60Hz |
Hydraulics
| HPU 2×64 kW w/75 ccm pumps |
Navigation and communication
| Furuno Radar IMO cat 3 |
| Olex chart plotter |
| Telchart dual ecdis chart system |
| Sailor Radio VHD |
| Furuno digital echo sounder |
| Autopilot Furuno Navpilot |
| Phototech intern communication |
| Broadband GSM 2 x 4G |
| Navy KVM Multiview Matrix |
| mLINK monitor |
Cranes
| -Palfinger PFM 2500 (capasity 188 tm) Reach: appr 19,7 m, with 10 t mounted winch Rotation: Continuous |
| -Palfinger PK 150002 (M) G Reach: appr 21.5 m, with 6,5 t mounted winch Rotation: Continuous |
| Both with scanreco radio control |
Capstans
| 1 x 8 t electric |
| 1 x 5 t electric |
| Both included foot pedals and emergency stops |
Other
| SHM Jark Shaw |
| SHM Towing pins |
| SHM 80/60t winch, 2500mm, drum, load and length measurement |
| SHM Mooring Lock ML400 WLL25ton |
| SHM Stern Roller, Ø 800, 3,5 m length |
| SHM Control System Premium with display and joystick in wheelhouse |
